New release DASIFN+ board to fix 'can not stop scan during continuous bad raw data' issue.
| 5117243-2 | |
| 5117243 5119728 | |
| Computed Tomography (CT) | |
| Other Computed Tomography (CT) | |
| GE HealthCare | 되사기 |
위시리스트에 추가
로그인 하고 장바구니에 추가
날짜를 선택하세요
두 번째 의견 승인 필요
승인 번호를 입력하고 장바구니에 품목을 추가하도록 제출하십시오.
승인 번호
Please enter approval number
OR
승인 번호를 모르십니까? 800-437-1171로 전화하십시오.
처음 세 개의 프롬프트에 opt 1을 입력하고 시스템 ID를 사용할 수 있도록하십시오.
장바구니에 품목을 추가하고
승인 번호, GE는 배송을 위해 주문을 확인하기 전에 연락을 드릴 것입니다.
두 번째 의견 승인 필요
Select your approver's name and submit to add item(s) to your cart
Approver Name
Please Select Approver Name
OR
Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.
If you add item(s) to cart and submit your order without
selecting an approver, GE will contact you before your order
can be confirmed for shipment.
특색
- Field Replaceable Unit (FRU)
- Higher reliability and efficiency
- Easy to connect / disconnect
- Compact size
제품 개요
The New release DASIFN (Data Acquisition System Interface Board) Plus Board is a part of in DASIFN plus pannel assembly. This board acts as the main interface between the DCP/DTRF and the Operator Console. It receives scan data in a high-speed serial stream from the slip ring interface and transmits it to the DBPCI (DAS Buffer PCI) Board. The board has a reset button for resetting the DASIFN PLUS Board.The input power required in the board is +5 VDC. The Board has status LED's for both power and other control signals. The board has HFBR-5205 transceiver with 1300 nm, 62.5/125 glass fiber optic cable for the slip ring interface and two 50 pin SCSI connecter for interface with DBPCI board.
추가 기능
- On Board Status LED's
- No calibration requirements
- GSPO
동등 품목:
아래는 동등한 부품에 대한 자세한 정보입니다. 하이퍼 링크가없는 부품은 참조 용으로 만 나열되며 온라인으로 구입할 수 없습니다.
| 동등 품목 | 제품 세부 사항 |
|---|---|
| 5117243 | DASIFN PLUS Board ASSY |
| 5119728 | GE Part |
